2

RATED CAPACITY

Kg

2000

3

 LOAD CENTRE

mm

500

4

 LIFTING HEIGHT

mm

B

3000

BASED

5

MAX.HEIGHT(FORK CARRAGE)

mm

A

4030

6

MAST HEIGHT

mm

C

2045

DATA

7

FREE LIFT HEIGHT

mm

E

300

8

MAST INCLINATION(F/R)

o

Y

6\12

9

FORK LENGTH

mm

J

1070

10

SUSPENSION(F/R)

mm

U

495/415

11

BRAKING DISTANCE(UNLOADED)

m

F

6

12

LOADED

mm/s

K

430

13

LIFTING SPEED

UNLOADED

mm/s

M

450

14

LOADED

mm/s

550

15

LOWERING SPEED

UNLOADED

mm/s

300

PERFORMANCE

16

LOADED

mm/s

18

17

TRAVELLING SPEED

UNLOADED

mm/s

20

DATA

18

MIN.TURNING RADIUS(OUTSIDE)

mm

W

2170

19

MIN.TURNING RADIUS(INSIDE)

mm

V

155

20

MIN.WIDTH OF ANGLEAISLE

mm

X

1900

21

MAX. GRADIENT

%

15/18

22

FRONT

Kg

4752

23

AXLELOAD(LOADED)

REAR

Kg

588

24

FRONT

Kg

1503

25

AXLELOAD(UNLOADED)

REAR

Kg

1837

26

OVERALL LENGTH(DISCLUDE FORK)

mm

H

2485

27

OVERALL WIDTH

mm

Q

1150

28

OVERALL HEIGHT(OVERHEAD GUARD)

mm

P

2075

29

WHEEL BASE

mm

L

1600

SIZE

30

FRONT

mm

S

970

AND

31

TRACK

REAR

mm

T

970

WEIGHT

32

MIN.GROUND CLEARANCE

mm

G

110

33

HEIGHT OF TRACT PIN

mm

N

245

34

HEIGHT FROM SEAT TO OVERHEAD GUARD

mm

O

960

35

SPACING(OUT-TO-OUT)

mm

R

300-1040

36

SERVICE WEIGHTS

Kg

3340

ENGINE

37

MODEL

A490BPG-50

38

DISPLACEMENT

L

2.54

39

RATED OUTPUT

kw

37kw/2650rpm

40

MAX. TORQUE

Nm

145Nm/2000rpm

41

CYLINDER

4

42

POWER TYPE

diesel

43

GEAR SHIFT(F)

1-1power shift

TRANSMISSION

44

GEAR SHIFT(R)

2-2hand shift

45

DRIVING BRAKE

hydraulic pedal

BRAKING TYPE

46

PARKING BRAKE

mechanical hand

47

FRONT TYRE (PNEUMATIC)

28x9-15-12PR

48

REAR TYRE (PNEUMATIC)

6.50-10-10PR

TYRE

49

PRESSURE

Mpa

0.7

50

VOLTAGE

V

12

BATIERY

51

CAPACITY

AH

N70

 TRANSMISSION TYPE

HYDRAULIC
